'3D Programming Graphics Visual Basic Express Edition'
'======================================================================='
' Source code Tutorial===>>>
Klik Disini'
' Berbagi ilmu Sensasi Kepuasan Tersendiri '
' Visual By: Verynandus Hutabalian'
' Publish to V. Hutabalian's Blog 18 Agustus 2010 '
'+++++++++++++++++++++++========================++++++++++++++++++++++++'
Imports System
Imports System.Drawing
Imports System.Drawing.Drawing2D
Public Enum RotateHorizontal
Left = -1
Center = 0
Right = 1
End Enum
Public Enum RotateVertical
Up = -1
Center = 0
Down = 1
End Enum
Public Enum CubeSides
Left
Right
Top
Bottom
Front
Back
End Enum
Public Structure Cube
Private FLocation As Point
Private FHeight As Integer
Private FWidth As Integer
Private FDepth As Integer
Private FCenter As Point
Private FPath As GraphicsPath
Private FRotateX As RotateHorizontal
Private FRotateY As RotateVertical
Public Property Location() As Point
Get
Return FLocation
End Get
Set(ByVal Value As Point)
FLocation = Value
Changed()
End Set
End Property
Public Property Height() As Integer
Get
Return FHeight
End Get
Set(ByVal Value As Integer)
FHeight = Value
Changed()
End Set
End Property
Public Property Width() As Integer
Get
Return FWidth
End Get
Set(ByVal Value As Integer)
FWidth = Value
Changed()
End Set
End Property
Public Property Depth() As Integer
Get
Return FDepth
End Get
Set(ByVal Value As Integer)
FDepth = Value
Changed()
End Set
End Property
Public Property Center() As Point
Get
Return FCenter
End Get
Set(ByVal Value As Point)
FCenter = Value
Changed()
End Set
End Property
Public ReadOnly Property Path() As GraphicsPath
Get
Return FPath
End Get
End Property
Public Property RotateX() As RotateHorizontal
Get
Return FRotateX
End Get
Set(ByVal Value As RotateHorizontal)
FRotateX = Value
Changed()
End Set
End Property
Public Property RotateY() As RotateVertical
Get
Return FRotateY
End Get
Set(ByVal Value As RotateVertical)
FRotateY = Value
Changed()
End Set
End Property
Public ReadOnly Property X() As Integer
Get
Return FLocation.X
End Get
End Property
Public ReadOnly Property Y() As Integer
Get
Return FLocation.Y
End Get
End Property
'Return the rectangle that bounds the entire polygon
'representing the cube
Public ReadOnly Property BoundsRect() As Rectangle
Get
If (FPath Is Nothing) Then
Return New Rectangle(0, 0, 0, 0)
Else
Dim r As RectangleF = Path.GetBounds()
' Implicit conversion from single to integer,
' really only available in VB
Return New Rectangle(r.X, r.Y, r.Width, r.Height)
End If
End Get
End Property
Public ReadOnly Property Item(ByVal index As CubeSides) As Point()
Get
Select Case index
Case CubeSides.Back
Return Back
Case CubeSides.Front
Return Front
Case CubeSides.Left
Return Left
Case CubeSides.Right
Return Right
Case CubeSides.Top
Return Top
Case CubeSides.Bottom
Return Bottom
Case Else
Return Front
End Select
End Get
End Property
Public ReadOnly Property Top() As Point()
Get
Return GetTop(Location, Height, Width, Depth, _
RotateX, RotateY)
End Get
End Property
Public ReadOnly Property Bottom() As Point()
Get
Return GetBottom(Location, Height, Width, Depth, _
RotateX, RotateY)
End Get
End Property
Public ReadOnly Property Left() As Point()
Get
Return GetLeft(Location, Height, Width, Depth, _
RotateX, RotateY)
End Get
End Property
Public ReadOnly Property Right() As Point()
Get
Return GetRight(Location, Height, Width, Depth, _
RotateX, RotateY)
End Get
End Property
Public ReadOnly Property Front() As Point()
Get
Return GetFront(Location, Height, Width, Depth, _
RotateX, RotateY)
End Get
End Property
Public ReadOnly Property Back() As Point()
Get
Return GetBack(Location, Height, Width, Depth, _
RotateX, RotateY)
End Get
End Property
Public Sub New(ByVal x As Integer, ByVal Y As Integer, _
ByVal height As Integer, ByVal width As Integer, _
ByVal depth As Integer, ByVal rotateX As RotateHorizontal, _
ByVal rotateY As RotateVertical)
FPath = New GraphicsPath
FLocation = New Point(x, Y)
FHeight = height
FWidth = width
FDepth = depth
FRotateX = rotateX
FRotateY = rotateY
FCenter = New Point(Location.X + (width + depth / 2 * _
rotateX) / 2, _
Location.Y + (height + depth / 2 * rotateY) / 2)
ConstructPath()
End Sub
Public Sub New(ByVal x As Integer, ByVal Y As Integer, _
ByVal height As Integer, ByVal width As Integer, _
ByVal depth As Integer)
FPath = New GraphicsPath
FLocation = New Point(x, Y)
FHeight = height
FWidth = width
FDepth = depth
FRotateX = RotateHorizontal.Right
FRotateY = RotateVertical.Up
FCenter = New Point(Location.X + (width + depth / 2 * _
RotateX) / 2, _
Location.Y + (height + depth / 2 * RotateY) / 2)
ConstructPath()
End Sub
Public Sub New(ByVal point As Point, _
ByVal height As Integer, ByVal width As Integer, _
ByVal depth As Integer)
FPath = New GraphicsPath
FLocation = point
FHeight = height
FWidth = width
FDepth = depth
FRotateX = RotateHorizontal.Right
FRotateY = RotateVertical.Up
FCenter = New Point(Location.X + (width + depth / 2 * _
RotateX) / 2, _
Location.Y + (height + depth / 2 * RotateY) / 2)
ConstructPath()
End Sub
Private Sub Changed()
ConstructPath()
End Sub
Private Sub ConstructPath()
FPath = New GraphicsPath
Path.AddLines(GetBack(Location, Height, Width, Depth, _
RotateX, RotateY))
Path.AddLines(GetFront(Location, Height, Width, Depth, _
RotateX, RotateY))
Path.AddLines(GetTop(Location, Height, Width, Depth, _
RotateX, RotateY))
Path.AddLines(GetBottom(Location, Height, Width, Depth, _
RotateX, RotateY))
Path.AddLines(GetLeft(Location, Height, Width, Depth, _
RotateX, RotateY))
Path.AddLines(GetRight(Location, Height, Width, Depth, _
RotateX, RotateY))
End Sub
Private Function GetXFromCenter(ByVal newCenter As Point) _
As Integer
Return newCenter.X - (FWidth + FDepth / 2 * FRotateX) / 2
End Function
Private Function GetYFromCenter(ByVal newCenter As Point) _
As Integer
Return newCenter.Y - (FHeight + FDepth / 2 * FRotateY) / 2
End Function
Public Sub FilleRectangle(ByVal boundingRect As Rectangle)
Dim x As Integer
If (FRotateX = RotateHorizontal.Right) Then
x = 0
Else
x = Math.Abs(Depth / 2 * FRotateX)
End If
Dim y As Integer
If (FRotateY = RotateVertical.Down) Then
y = 0
Else
y = Math.Abs(Depth / 2 * RotateY)
End If
FLocation = New Point(x, y)
FWidth = boundingRect.Width - Depth / 2 - 1
FHeight = boundingRect.Height - Depth / 2 - 1
ConstructPath()
End Sub
Public Function GetCube() As GraphicsPath
Return FPath
End Function
Public Function GetSides(ByVal theseSides As CubeSides()) _
As GraphicsPath
Dim newPath As GraphicsPath = New GraphicsPath
Dim I As Integer
For I = 0 To theseSides.Length - 1
newPath.AddLines(Item(theseSides(I)))
Next I
Return newPath
End Function
Public Shared Function GetXOffset(ByVal depth As Integer, _
ByVal rotateX As RotateHorizontal) As Integer
Return depth / 2 * rotateX
End Function
Public Shared Function GetYOffset(ByVal depth As Integer, _
ByVal rotateY As RotateVertical) As Integer
Return depth / 2 * rotateY
End Function
Public Shared Function GetTop(ByVal point As Point, _
ByVal height As Integer, _
ByVal width As Integer, _
ByVal depth As Integer, _
ByVal rotateX As RotateHorizontal, _
ByVal rotateY As RotateVertical) _
As Point()
Return New Point() { _
New Point(point.X, point.Y), _
New Point(point.X + GetXOffset(depth, rotateX), point.Y + _
GetYOffset(depth, rotateY)), _
New Point(point.X + width + GetXOffset(depth, rotateX), _
point.Y + GetYOffset(depth, rotateY)), _
New Point(point.X + width, point.Y), _
New Point(point.X, point.Y)}
End Function
Public Shared Function GetLeft(ByVal point As Point, _
ByVal height As Integer, _
ByVal width As Integer, ByVal depth As Integer, _
ByVal rotateX As RotateHorizontal, _
ByVal rotateY As RotateVertical)
Return New Point() {New Point(point.X, point.Y), _
New Point(point.X + GetXOffset(depth, rotateX), _
point.Y + GetYOffset(depth, rotateY)), _
New Point(point.X + GetXOffset(depth, rotateX), _
point.Y + GetYOffset(depth, rotateY) + height), _
New Point(point.X, point.Y + height), _
New Point(point.X, point.Y)}
End Function
Public Shared Function GetRight(ByVal point As Point, _
ByVal height As Integer, _
ByVal width As Integer, ByVal depth As Integer, _
ByVal rotateX As RotateHorizontal, ByVal rotateY _
As RotateVertical)
Return New Point() {New Point(point.X + width, point.Y), _
New Point(point.X + width + GetXOffset(depth, rotateX), _
point.Y + GetYOffset(depth, rotateY)), _
New Point(point.X + width + GetXOffset(depth, rotateX), _
point.Y + GetYOffset(depth, rotateY) + height), _
New Point(point.X + width, point.Y + height), _
New Point(point.X + width, point.Y)}
End Function
Public Shared Function GetBottom(ByVal point As Point, _
ByVal height As Integer, _
ByVal width As Integer, ByVal depth As Integer, _
ByVal rotateX As RotateHorizontal, _
ByVal rotateY As RotateVertical) As Point()
Return New Point() {New Point(point.X, point.Y + height), _
New Point(point.X + GetXOffset(depth, rotateX), _
point.Y + GetYOffset(depth, rotateY) + height), _
New Point(point.X + width + GetXOffset(depth, rotateX), _
point.Y + GetYOffset(depth, rotateY) + height), _
New Point(point.X + width, point.Y + height), _
New Point(point.X, point.Y + height)}
End Function
Public Shared Function GetFront(ByVal point As Point, _
ByVal height As Integer, _
ByVal width As Integer, ByVal depth As Integer, _
ByVal rotateX As RotateHorizontal, ByVal rotateY _
As RotateVertical) As Point()
Return New Point() {point, New Point(point.X + width, point.Y), _
New Point(point.X + width, point.Y + height), _
New Point(point.X, point.Y + height), point}
End Function
Public Shared Function GetBack(ByVal point As Point, _
ByVal height As Integer, _
ByVal width As Integer, ByVal depth As Integer, _
ByVal rotateX As RotateHorizontal, _
ByVal rotateY As RotateVertical) As Point()
Dim topLeft As Point = New Point(point.X + _
GetXOffset(depth, rotateX), _
point.Y + GetYOffset(depth, rotateY))
Dim topRight As Point = New Point(point.X + width + _
GetXOffset(depth, rotateX), point.Y + _
GetYOffset(depth, rotateY))
Dim bottomRight As Point = New Point(point.X + width + _
GetXOffset(depth, rotateX), point.Y + height + _
GetYOffset(depth, rotateY))
Dim bottomLeft As Point = New Point(point.X + _
GetXOffset(depth, rotateX), point.Y + height + _
GetYOffset(depth, rotateY))
Return New Point() {topLeft, topRight, bottomRight, _
bottomLeft, topLeft}
End Function
End Structure
Public Class Form1
Inherits System.Windows.Forms.Form
Private cube As Cube = New Cube(100, 100, 100, 200, 50)
Private Sub Form1_Paint(ByVal sender As Object, _
ByVal e As System.Windows.Forms.PaintEventArgs) _
Handles MyBase.Paint
e.Graphics.DrawPath(Pens.Red, cube.GetCube())
End Sub
End Class
